Used and Refurbished Dell PowerVault ME512

ME5 Series Expansion Enclosure | 2U Rack
  Contact Us To Get Started

Maximize the capacity of your Dell PowerVault ME5 storage environment with the PowerVault ME512 expansion enclosure. The ME512 is a compact 2U expansion chassis providing 12 x 3.5-inch drive bays and connecting to supported ME5 base arrays over a 12Gb SAS expansion interface. Designed for capacity-oriented deployments, the ME512 provides an efficient way to add high-capacity storage to PowerVault ME5212 or ME5224 arrays without adding another independent storage system.

Up to nine 2U expansion enclosures can be attached to a supported 2U ME5 base array. The broader ME5 platform supports SAS and NL-SAS media, including high-capacity 3.5-inch NLSAS drives, while the enclosure uses Dell's 12Gb SAS backend for capacity expansion. The ME512 measures 2U high and 23.74 inches deep, with a maximum configured weight of 62 pounds.

PowerVault ME512 Technical Specifications

Rack Size:
 2U
Drive Bays:
 12 x 3.5” drive bays
Compatible Base Arrays:
 PowerVault ME5212 and ME5224
Max Expansion Enclosures:
 Up to 9 2U expansion enclosures per supported 2U base array
Expansion Protocol:
 12Gb SAS
Expansion Interface:
 2 x 12Gb SAS (wide-Port) per array, 1 port per controller
Storage Media:
 SAS and NL-SAS drives; different drive types, transfer rates and rotational speeds can be mixed within the ME5 system:
• NLSAS 7.2K 3.5” – 4TB, 8TB, 8TB FIPS, 12TB, 16TB, 16TB FIPS, 20TB, 24TB
• SAS 10K 2.5” – 1.2TB, 2.4TB, 2.4TB FIPS
• SSD – 1.6TB MU, 1.92TB RI, 3.84TB RI, 3.2TB FIPS MU, 7.68TB RI
Dimensions:
 Height: 8.79 cm (3.46 inches)
Width: 48.30 cm (19.01 inches)
Depth: 60.29 cm (23.74 inches)
Weight, max configuration: 28.00 kg (62.00 lbs)
Weight, empty: 4.80 kg (10.56 lbs) without drives
Power:
 Power/Wattage: 580W
Heat Dissipation: 1980 BTU
Voltage: 100-240 VAC
Frequency: 50/60 Hz
Amperage: 7.6-3.0A (x2)
Environmental Operating Conditions:
 Operating temperature: 5°C - 35°C (41°F - 95°F, derated by 1°C per 300mm above 900m)
Non-operating temperature: -40°C to 70°C (-40°F to 158°F); maximum temperature change in an hour: 20°C
Operating humidity: -12°C dew point minimum, 8% to 85% maximum, non-condensing
Non-operating humidity: 21°C dew point maximum, 5% to 100% maximum, non-condensing

More information can be found on the official Dell PowerVault ME5200 Series Specification Sheet.
