Used and Refurbished Dell PowerEdge R360

16th Gen | 1U Rack Server | 1 Socket

The Dell PowerEdge R360 is a 1U single-processor rack server built to deliver affordable enterprise performance for growing businesses and space-conscious deployments. Powered by an Intel Xeon 6300 series, Intel Xeon E-2400 series, or Intel Pentium G7400/G7400T processor, the R360 is designed for productivity and data-intensive business applications while maintaining a compact footprint. With support for up to 128GB of DDR5 UDIMM memory at speeds up to 4400 MT/s, plus flexible front-bay storage options and NVMe BOSS-N1 boot support, the R360 provides streamlined performance and scalability for common business workloads. It also supports an NVIDIA A2-class GPU configuration with up to one 60W single-width GPU for environments that need entry-level acceleration.

Purpose-built for small to mid-sized businesses, ROBO and near-edge environments, the PowerEdge R360 is ideal for collaboration and sharing, database support and management, and general business infrastructure. Dell positions it as an easy-to-manage, reliable, and secure platform with iDRAC9 management, strong OpenManage integration, optional filter bezel protection for harsher environments, and enterprise security features designed to support dependable day-to-day operation both inside and outside the traditional data center.

PowerEdge R360 Technical Specifications

Form Factor:
1U Rack Server
Processors:
• One Intel Xeon 6300 series or one Intel Xeon E-2400 series processor with up to 8 cores
• One Intel Pentium G7400/G7400T processor with 2 cores
Memory:
• 4 DDR5 DIMM slots, supports UDIMM 128 GB max, speeds up to 4400 MT/s
• Supports unregistered ECC DDR5 DIMMs only
Storage Controllers:
• Internal Controllers: HBA355i Adpt, PERC H355 Adpt, PERC H755 Adpt, HBA355i front, H355 front, H755 front
• Internal Boot: Internal USB 3.0, or Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 SSDs, USB
• External HBAs (non-RAID): HBA355e Adpt
• Software Controller: S160
Drive Bays:
Front Bays:
  • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB
  • Up to 8 x 2.5-inch SAS/SATA (SSD) max 61.44 TB
Power Supplies:
• 600 W Platinum 100 — 240 VAC or 240 VDC, hot swap redundant
• 700 W Titanium 200 — 240 VAC or 240 VDC, hot swap redundant
Cooling Options:
Air cooling
Fans:
• Up to 4 fans
Dimensions:
• Height – 42.8 mm (1.68 inches)
• Width – 482.0 mm (18.97 inches)
• Depth – 585.3 mm (23.04 inches) without bezel
• Depth – 598.9 mm (23.57 inches) with bezel
Embedded Management:
• iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Manual
Bezel:
Security bezel or optional filter bezel
OpenManage Software:
• OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage Service plugin
• OpenManage Update Manager plugin
• CloudIQ for PowerEdge plug in
• OpenManage Enterprise Integration for VMware vCenter
• OpenManage Integration for Microsoft System Center
• OpenManage Integration with Windows Admin Center
Mobility:
OpenManage Mobile
OpenManage Integrations:
• BMC Truesight
• Microsoft System Center
• OpenManage Integration with ServiceNow
• Red Hat Ansible Modules
• Terraform Providers
• VMware vCenter and vRealize Operations Manager
Security:
• Cryptographically signed firmware
• Data at Rest Encryption (SEDs with local or external key mgmt)
• Secure Boot
• Secured Component Verification (Hardware integrity check)
• Secure Erase
• Secured-core server
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC:
2 x 1 GbE LOM
Network Options:
Not listed in the spec sheet
GPU Options:
1 x 60 W single-width GPU
Ports:
Front Ports
  • 1 x iDRAC Direct (Micro-AB USB) port
  • 1 x USB 2.0
Rear Ports
  • 1 x Dedicated iDRAC Ethernet port
  • 1 x USB 2.0
  • 1 x USB 3.2 Gen1
  • 1 x VGA
  • 1 x Serial
Internal Ports
  • 1 x USB 3.2 Gen1
PCIe:
Up to two PCIe Gen4 slots on the Gen4 riser
  • Slot 1: 1 x8 with x8 bandwidth, half length, low profile
  • Slot 2: 1 x16 with x8 bandwidth, half length, low profile
• One dedicated PCIe x8 slot on the system board for internal PERC
Operating Systems & Hypervisors:
• Canonical Ubuntu Server LTS
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi

More information can be found on the official Dell PowerEdge R360 Specs PDF.
