PowerEdge T440 Technical Specifications
Form Factor:
5U Tower or Rack Mount
Chassis Depth:
Max depth: 594.82mm
Processors:
Up to two 2nd Generation Intel Xeon Scalable processors, up to 28 cores per processor
Memory:
16 DDR4 DIMM slots, Supports RDIMMs/LRDIMMs, speeds up to 2666MT/s, 1TB* max
Supports registered ECC DDR4 DIMMs only
Storage Controllers:
Internal controllers: PERC H330, H730P, H740P, HBA330, Software RAID (SWRAID) S140
Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB
External PERC (RAID): H840
External HBAs (non-RAID): 12 Gbps SAS HBA
Drive Bays:
Up to 8 x 3.5” SAS/SATA (HDD/SSD) max 128TB or
Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB
Power Supplies:
495W, 750W, 1100W hot-plug; Gold efficiency
450W Cabled AC PSU
Up to 2 fans
Embedded / At-ServerManagement:
iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC REST API with Redfish
Bezel:
Optional security bezel
Consoles & Mobile:
OpenManage Enterprise
OpenManage Mobile
OpenManage Power Manager
Integrations and Connections:
OpenManage Integrations: Microsoft® System Center, VMware® vCenter™, BMC Software
OpenManage Connections: Nagios & Nagios XI, HP Operations Manager i (OMi)
Tools:
Dell EMC Repository Manager
Dell EMC Update Package
Dell EMC System Update
Dell EMC Server Update Utility
iDRAC Service Module
OpenManage Server Administrator
OpenManage Storage Services
Security:
TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown
Secure erase
I/O & Ports:
2 x 1GbE LOM
1 dedicated iDRAC port
9 x USB (5 x USB 2.0, 4 x USB 3.0), including one internal USB port
1 VGA video port and 1 serial port
Up to 5 PCIe Gen3 slots
GPU:
1X NVIDIA NVS 310
1X NVIDIA Quadro P4000
Supported Operating Systems:
Canonical® Ubuntu® LTS
Citrix® Hypervisor
Microsoft Windows Server® LTSC with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
More information can be found on the official Dell PowerEdge T440 Specs PDF.
Form Factor: |
5U Tower or Rack Mount |
Chassis Depth: |
Max depth: 594.82mm |
Processors: |
Up to two 2nd Generation Intel Xeon Scalable processors, up to 28 cores per processor |
Memory: |
16 DDR4 DIMM slots, Supports RDIMMs/LRDIMMs, speeds up to 2666MT/s, 1TB* max Supports registered ECC DDR4 DIMMs only |
Storage Controllers: |
Internal controllers: PERC H330, H730P, H740P, HBA330, Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB External PERC (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA |
Drive Bays: |
Up to 8 x 3.5” SAS/SATA (HDD/SSD) max 128TB or Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB |
Power Supplies: |
495W, 750W, 1100W hot-plug; Gold efficiency 450W Cabled AC PSU Up to 2 fans |
Embedded / At-ServerManagement: |
iDRAC9 with Lifecycle Controller iDRAC Direct iDRAC REST API with Redfish |
Bezel: |
Optional security bezel |
Consoles & Mobile: |
OpenManage Enterprise OpenManage Mobile OpenManage Power Manager |
Integrations and Connections: |
OpenManage Integrations: Microsoft® System Center, VMware® vCenter™, BMC Software OpenManage Connections: Nagios & Nagios XI, HP Operations Manager i (OMi) |
Tools: |
Dell EMC Repository Manager Dell EMC Update Package Dell EMC System Update Dell EMC Server Update Utility iDRAC Service Module OpenManage Server Administrator OpenManage Storage Services |
Security: |
TPM 1.2/2.0 optional Cryptographically signed firmware Silicon Root of Trust Secure Boot System Lockdown Secure erase |
I/O & Ports: |
2 x 1GbE LOM 1 dedicated iDRAC port 9 x USB (5 x USB 2.0, 4 x USB 3.0), including one internal USB port 1 VGA video port and 1 serial port Up to 5 PCIe Gen3 slots |
GPU: |
1X NVIDIA NVS 310 1X NVIDIA Quadro P4000 |
Supported Operating Systems: |
Canonical® Ubuntu® LTS Citrix® Hypervisor Microsoft Windows Server® LTSC with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
More information can be found on the official Dell PowerEdge T440 Specs PDF.
