Intel Xeon 8 Core E5-2667v4 (3.20GHz, 25M, 135W) SR2P5

This Intel Xeon E5-2667 v4 processor is an 8-core, 16-thread Broadwell server CPU for Intel Xeon E5 v4 platforms using the FCLGA2011 socket. With a 3.20GHz base frequency, up to 3.60GHz turbo frequency, 25MB cache, and 135W TDP, it is commonly used where stronger per-core performance is preferred over maximum core count. It supports DDR4 memory up to 2400MHz across four memory channels, ECC memory, 40 PCIe 3.0 lanes, and up to two processors per system; compatibility depends on BIOS support for E5 v4 processors, the FCLGA2011 socket, processor matching in dual-CPU configurations, and heatsink and airflow support for a 135W CPU.

Manufacturer Part #
SR2P5
Product Collection
Intel Xeon Processor E5 v4 Family
Code Name
Broadwell
Vertical Segment
Server
Processor Number
E5-2667V4
Lithography
14 nm
Total Cores
8
Total Threads
16
Base Frequency
3.2 GHz
Max Turbo Frequency
3.6 GHz
Cache
25.0 MB
Bus Speed
9.6 GT/s
Max QPI Links
2
TDP
135 W
Max Memory Size
768 GB
Memory Types
DDR4 1600/1866/2133/2400
Max Memory Speed
2400 MHz
Max Memory Channels
4
Max Memory Bandwidth
76.8 GB/s
ECC Memory Supported
true
PCI Express Revision
3
Max PCI Express Lanes
40
Sockets Supported
FCLGA2011
Max CPU Configuration
2
Spec Code
SR2P5
Condition
Refurbished
6 In Stock
$39
$39
