Intel

Intel Platinum 8156 4 Core (3.60Ghz, 16.5M L3 105W) SR3AV

This Intel Xeon Platinum 8156 is a 1st Gen Intel Xeon Scalable server processor for FCLGA3647 platforms. It provides 4 cores and 8 threads with a 3.60GHz base frequency, up to 3.70GHz turbo frequency, 16.5MB of L3 cache, and a 105W TDP, making it a high-frequency option within the Skylake Xeon Scalable family. The processor supports six-channel DDR4-2666 ECC memory up to 768GB per CPU and provides 48 PCIe 3.0 lanes. Compatibility depends on motherboard support for Xeon Scalable 8156 CPUs, BIOS level, socket type, 105W thermal capacity, heatsink and fan configuration, and the system’s supported memory population rules.

Manufacturer Part #
SR3AV
Product Collection
Intel Xeon Scalable Processors
Code Name
Skylake
Vertical Segment
Server
Processor Number
8156
Lithography
14 nm
Total Cores
4
Total Threads
8
Base Frequency
3.6 GHz
Max Turbo Frequency
3.7 GHz
Cache
16.5 MB
Max UPI Links
3
TDP
105 W
Max Memory Size
768 GB
Memory Types
DDR4-2666
Max Memory Speed
2666 MHz
Max Memory Channels
6
ECC Memory Supported
true
PCI Express Revision
3
Max PCI Express Lanes
48
Sockets Supported
FCLGA3647
Max CPU Configuration
8
Spec Code
SR3AV
Dell Server Generation
14
Condition
Refurbished
Out Of Stock
$39
$39
