Intel

Intel Gold 5120T 14 Core (2.2Ghz, 19.25M 105W) SR3GC

This Intel Xeon Gold 5120T is a 14-core, 28-thread server processor for FCLGA3647 platforms with BIOS support for first-generation Intel Xeon Scalable Gold 5100-series Skylake CPUs. It runs at a 2.2GHz base frequency with up to 3.2GHz turbo frequency, 19.25MB cache, and a 105W TDP, and it supports six-channel DDR4-2400 ECC memory, up to 768GB of memory capacity, 48 PCIe 3.0 lanes, and two UPI links for multi-processor server configurations. Compatibility depends on the server board and BIOS, supported CPU population rules, correct heatsink and fan configuration, and chassis airflow designed for a 105W processor.

Manufacturer Part #
SR3GC
Product Collection
Intel Xeon Scalable Processors
Code Name
Skylake
Vertical Segment
Server
Processor Number
5120T
Lithography
14 nm
Total Cores
14
Total Threads
28
Base Frequency
2.2 GHz
Max Turbo Frequency
3.2 GHz
Cache
19.25 MB
Max UPI Links
2
TDP
105 W
Max Memory Size
768 GB
Memory Types
DDR4-2400
Max Memory Speed
2400 MHz
Max Memory Channels
6
ECC Memory Supported
true
PCI Express Revision
3
Max PCI Express Lanes
48
Sockets Supported
FCLGA3647
Max CPU Configuration
4
Spec Code
SR3GC
Dell Server Generation
14
Condition
Refurbished
Out Of Stock
$39
$39
