Intel

Intel Gold 5120 14 Core (2.20Ghz, 19.25M 105W) SR3GD

This Intel Xeon Gold 5120 processor is a 14-core, 28-thread Skylake server CPU for platforms using the FCLGA3647 socket and 1st Gen Intel Xeon Scalable processor family. It runs at a 2.20GHz base frequency with up to 3.20GHz turbo frequency, includes 19.25MB of cache, and has a 105W TDP, with support for six-channel DDR4-2400 ECC memory and up to 48 PCIe 3.0 lanes from the processor. Compatibility depends on the server’s supported CPU list, BIOS level, socket and processor-generation support, heatsink and fan configuration for 105W CPUs, memory population, and any single-, dual-, or four-socket processor population rules used by the system.

Manufacturer Part #
SR3GD
Product Collection
Intel Xeon Scalable Processors
Code Name
Skylake
Vertical Segment
Server
Processor Number
5120
Lithography
14 nm
Total Cores
14
Total Threads
28
Base Frequency
2.2 GHz
Max Turbo Frequency
3.2 GHz
Cache
19.25 MB
Max UPI Links
2
TDP
105 W
Max Memory Size
768 GB
Memory Types
DDR4-2400
Max Memory Speed
2400 MHz
Max Memory Channels
6
ECC Memory Supported
true
PCI Express Revision
3
Max PCI Express Lanes
48
Sockets Supported
FCLGA3647
Max CPU Configuration
4
Spec Code
SR3GD
Dell Server Generation
14
Condition
Refurbished
Out Of Stock
$9
$9
