Intel

Intel 20 Core E5-2698v4 (2.20GHz, 50M, 9.6 GT/s, 135W) SR2JW

This Intel Xeon E5-2698 v4 is a 20-core, 40-thread Broadwell server processor for platforms that support the Intel Xeon E5 v4 family and the FCLGA2011 socket. It runs at a 2.20GHz base frequency and up to 3.60GHz turbo frequency with 50MB cache, 9.6 GT/s QPI, and a 135W TDP, while supporting ECC DDR4 memory up to 2400MHz, four memory channels, two-socket configurations, and 40 PCIe 3.0 lanes per CPU. Compatibility depends on the motherboard’s E5 v4 CPU support, BIOS level, socket type, heatsink and airflow capacity for 135W processors, dual-processor pairing requirements, and supported memory population.

Manufacturer Part #
SR2JW
Product Collection
Intel Xeon Processor E5 v4 Family
Code Name
Broadwell
Vertical Segment
Server
Processor Number
E5-2698V4
Lithography
14 nm
Total Cores
20
Total Threads
40
Base Frequency
2.2 GHz
Max Turbo Frequency
3.6 GHz
Cache
50.0 MB
Bus Speed
9.6 GT/s
Max QPI Links
2
TDP
135 W
Max Memory Size
1500 GB
Memory Types
DDR4 1600/1866/2133/2400
Max Memory Speed
2400 MHz
Max Memory Channels
4
Max Memory Bandwidth
76.8 GB/s
ECC Memory Supported
true
PCI Express Revision
3
Max PCI Express Lanes
40
Sockets Supported
FCLGA2011
Max CPU Configuration
2
Spec Code
SR2JW
Condition
Refurbished
Out Of Stock
$79
$79
