Intel

Intel Silver 4316 20 Core (2.30GHz, 30M, 150W) SRKXH

This Intel Xeon Silver 4316 processor is a 20-core, 40-thread 3rd Gen Intel Xeon Scalable CPU for Ice Lake server platforms using the FCLGA4189 socket. It runs at a 2.30GHz base frequency with up to 3.40GHz turbo, includes 30MB of cache, and has a 150W TDP, while supporting DDR4-2667 ECC memory across up to eight channels, up to two 10.4 GT/s UPI links, and up to 64 PCIe 4.0 lanes for system I/O. Systems using this CPU need motherboard and BIOS support for 3rd Gen Xeon Scalable processors, an FCLGA4189 processor socket, heatsink and airflow capacity for a 150W CPU, and memory population that follows the server platform’s DDR4 channel rules; dual-socket installations should use processor pairings supported by the server manufacturer.

Product Collection
3rd Gen Intel Xeon Scalable Processors
Code Name
Ice Lake
Vertical Segment
Server
Processor Number
4316
Lithography
10 nm
Total Cores
20
Total Threads
40
Base Frequency
2.3 GHz
Max Turbo Frequency
3.4 GHz
Cache
30.0 MB
Intel UPI Speed
10.4 GT/s
Max UPI Links
2
TDP
150 W
Max Memory Size
6000 GB
Memory Types
DDR4-2667
Max Memory Speed
2667 MHz
Max Memory Channels
8
ECC Memory Supported
true
PCI Express Revision
4
Max PCI Express Lanes
64
Sockets Supported
FCLGA4189
Spec Code
SRKXH
Dell Server Generation
15
Condition
Refurbished
Variant:
4 In Stock
$1,399
$1,399
