Intel

Intel Platinum 8470N 1.7G, 52C/104T, 16GT/s, 97.5M Cache, Turbo, HT (300W) SRM7M

This Intel Xeon Platinum 8470N is a 4th Gen Intel Xeon Scalable server processor for FCLGA4677 platforms. It provides 52 cores and 104 threads with a 1.70GHz base frequency, up to 3.60GHz turbo frequency, 97.5MB cache, 16GT/s UPI, and a 300W TDP, while supporting 8-channel ECC DDR5 memory up to 4800 MT/s at 1DPC or 4400 MT/s at 2DPC and up to 80 PCIe 5.0 lanes. Compatibility depends on server support for Sapphire Rapids Xeon Scalable CPUs, BIOS/firmware level, FCLGA4677 socket support, 300W processor thermal limits, the correct heatsink and fan configuration, and the required DDR5 memory population.

Product Collection
4th Gen Intel Xeon Scalable Processors
Code Name
Sapphire Rapids
Vertical Segment
Server
Processor Number
8470N
Lithography
Intel 7
Total Cores
52
Total Threads
104
Base Frequency
1.7 GHz
Max Turbo Frequency
3.6 GHz
Cache
97.5 MB
Intel UPI Speed
16.0 GT/s
Max UPI Links
3
TDP
300 W
Max Memory Size
4000 GB
Memory Types
Up to DDR5 4800 MT/s 1DPC, Up to DDR5 4400 MT/s 2DPC
Max Memory Channels
8
ECC Memory Supported
true
PCI Express Revision
5
Max PCI Express Lanes
80
Sockets Supported
FCLGA4677
Spec Code
SRM7M
Dell Server Generation
16
Condition
Refurbished
Variant:
Out Of Stock
$3,999
$3,999
