Intel

Intel Max 9460 2.2G, 40C/80T, 16GT/s, 97.5M Cache, Turbo, HT (350W) SRMJD

This Intel Xeon CPU Max 9460 processor is a 40-core, 80-thread server CPU for platforms with FCLGA4677 socket support and Intel Xeon CPU Max Series BIOS support. It runs at a 2.20GHz base frequency with up to 3.50GHz turbo, includes 97.5MB cache, uses a 350W TDP, and supports 16GT/s Intel UPI links for multi-processor server designs.

The Max 9460 supports 8-channel ECC DDR5 memory, with speeds up to 4800 MT/s at 1DPC or 4400 MT/s at 2DPC, and provides up to 80 PCIe 5.0 lanes for high-bandwidth expansion. Compatibility depends on the server generation, FCLGA4677 socket board, BIOS level, 350W heatsink and airflow configuration, memory population rules, and whether the chassis and motherboard support the required UPI layout for single- or multi-socket operation.

Product Collection
Intel Xeon CPU Max Series
Code Name
Sapphire Rapids HBM
Vertical Segment
Server
Processor Number
9460
Lithography
Intel 7
Total Cores
40
Total Threads
80
Base Frequency
2.2 GHz
Max Turbo Frequency
3.5 GHz
Cache
97.5 MB
Intel UPI Speed
16.0 GT/s
Max UPI Links
3
TDP
350 W
Max Memory Size
4000 GB
Memory Types
Up to DDR5 4800 MT/s 1DPC, Up to DDR5 4400 MT/s 2DPC
Max Memory Channels
8
ECC Memory Supported
true
PCI Express Revision
5
Max PCI Express Lanes
80
Sockets Supported
FCLGA4677
Spec Code
SRMJD
Dell Server Generation
16
Condition
Refurbished
Variant:
Out Of Stock
$2,999
$2,999
