Intel

Intel Gold 6534 3.9G, 8C/16T, 20GT/s, 22.5M Cache, Turbo, HT (195W) SRN6A

Item Attributes
Manufacturer Intel
Manufacturer URL https://www.intel.com/content/www/us/en/products/sku/237555/intel-xeon-gold-6534-processor-22-5m-cache-3-90-ghz/specifications.html
CPU 01 - Product Collection 5th Gen Intel Xeon Scalable Processors
CPU 02 - Code Name Emerald Rapids
CPU 03 - Vertical Segment Server
CPU 04 - Processor Number 6534
CPU 05 - Lithography Intel 7
CPU 06 - Total Cores 8
CPU 07 - Total Threads 16
CPU 08 - Max Turbo Frequency GHz 4.2
CPU 09 - Processor Base Frequency GHz 3.9
CPU 10 - Cache MB 22.5
CPU 12 - Max QPI Links
CPU 13 - Intel UPI Speed GTs 20
CPU 14 - Max UPI Links 3
CPU 15 - TDP Wattage 195
CPU 16 - Max Memory Size GB 4000
CPU 17 - Memory Types Up to DDR5 4800 MT/s 1DPC
CPU 18 - Max Memory Speed MHz 4800
CPU 19 - Max Memory Channels 8
CPU 20 - Max Memory Bandwidth GBs
CPU 21 - Optane Memory Supported No
CPU 22 - ECC Memory Supported Yes
CPU 23 - PCI Express Revision 5
CPU 24 - Max PCI Express Lanes 80
CPU 25 - Sockets Supported FCLGA4677
CPU 26 - Max CPU Configuration
CPU 27 - Spec Code SRN6A
SRVR 03 - Generation 16
CPU 28 - Tier Gold
Visibility Visible Individually
Dell Part Numbers
Product Collection
5th Gen Intel Xeon Scalable Processors
Code Name
Emerald Rapids
Vertical Segment
Server
Processor Number
6534
Lithography
Intel 7
Total Cores
8
Total Threads
16
Base Frequency
3.9 GHz
Max Turbo Frequency
4.2 GHz
Cache
22.5 MB
Intel UPI Speed
20.0 GT/s
Max UPI Links
3
TDP
195 W
Max Memory Size
4000 GB
Memory Types
Up to DDR5 4800 MT/s 1DPC
Max Memory Speed
4800 MHz
Max Memory Channels
8
ECC Memory Supported
true
PCI Express Revision
5
Max PCI Express Lanes
80
Sockets Supported
FCLGA4677
Spec Code
SRN6A
Dell Server Generation
16
Variant:
Out Of Stock
$3,499.00
$3,499.00
