Intel Gold 6454S 2.2G, 32C/64T, 16GT/s, 60M Cache, Turbo, HT (270W) SRM7B

This Intel Xeon Gold 6454S is a 4th Gen Intel Xeon Scalable server processor for FCLGA4677 platforms. It provides 32 cores and 64 threads with a 2.20GHz base frequency, up to 3.40GHz turbo frequency, 60MB cache, 16GT/s Intel UPI, and a 270W TDP, supporting high-core-count server configurations with DDR5 memory and PCIe 5.0 I/O. Compatibility depends on server support for Sapphire Rapids processors, the FCLGA4677 socket, BIOS/firmware level, 270W thermal design, heatsink and fan configuration, and memory population rules, including up to DDR5-4800 at 1DPC or DDR5-4400 at 2DPC across 8 memory channels. Dual-socket use requires a supported two-processor board configuration and an appropriate processor pairing.

Product Collection
4th Gen Intel Xeon Scalable Processors
Code Name
Sapphire Rapids
Vertical Segment
Server
Processor Number
6454S
Lithography
Intel 7
Total Cores
32
Total Threads
64
Base Frequency
2.2 GHz
Max Turbo Frequency
3.4 GHz
Cache
60.0 MB
Intel UPI Speed
16.0 GT/s
Max UPI Links
4
TDP
270 W
Max Memory Size
4000 GB
Memory Types
Up to DDR5 4800 MT/s 1DPC, Up to DDR5 4400 MT/s 2DPC
Max Memory Speed
4800 MHz
Max Memory Channels
8
ECC Memory Supported
true
PCI Express Revision
5
Max PCI Express Lanes
80
Sockets Supported
FCLGA4677
Max CPU Configuration
2
Spec Code
SRM7B
Dell Server Generation
16
Condition
Refurbished
Variant:
Out Of Stock
$2,999
$2,999
