Intel

Intel Gold 5418N 1.8G, 24C/48T, 16GT/s, 45M Cache, Turbo, HT (165W) SRMGX

This Intel Xeon Gold 5418N processor is a 4th Gen Intel Xeon Scalable server CPU for FCLGA4677 platforms. It provides 24 cores and 48 threads with a 1.80GHz base frequency, up to 3.80GHz turbo frequency, 45MB cache, 16GT/s Intel UPI, and a 165W TDP, with support for 8-channel ECC DDR5 memory up to 4000MT/s and PCIe 5.0 expansion. Compatibility depends on the server’s 4th Gen Xeon Scalable processor support, BIOS level, socket and CPU population rules, heatsink and fan configuration, memory type and population, and 165W thermal envelope.

Product Collection
4th Gen Intel Xeon Scalable Processors
Code Name
Sapphire Rapids
Vertical Segment
Server
Processor Number
5418N
Lithography
Intel 7
Total Cores
24
Total Threads
48
Base Frequency
1.8 GHz
Max Turbo Frequency
3.8 GHz
Cache
45.0 MB
Intel UPI Speed
16.0 GT/s
Max UPI Links
3
TDP
165 W
Max Memory Size
4000 GB
Memory Types
Up to DDR5 4000 MT/s 1DPC and 2DPC
Max Memory Channels
8
ECC Memory Supported
true
PCI Express Revision
5
Max PCI Express Lanes
80
Sockets Supported
FCLGA4677
Spec Code
SRMGX
Dell Server Generation
16
Condition
Refurbished
Variant:
Out Of Stock
$2,699
$2,699
